| 規格 | 長度 | 齒數 | 規格 | 長度 | 齒數 | 規格 | 長度 | 齒數 | 規格 | 長度 | 齒數 | |||
| B104MXL | 211.328 | 104 | B195MXL | 396.24 | 195 | B354MXL | 719.328 | 354 | B705MXL | 1432.56 | 705 | |||
| B105MXL | 213.36 | 105 | B200MXL | 406.4 | 200 | B356MXL | 723.392 | 356 | B726MXL | 1475.232 | 726 | |||
| B106MXL | 215.392 | 106 | B205MXL | 416.56 | 205 | B358MXL | 727.456 | 358 | B750MXL | 1524.000 | 750 | |||
| B107MXL | 217.424 | 107 | B210MXL | 426.72 | 210 | B360MXL | 731.52 | 360 | B760MXL | 1544.32 | 760 | |||
| B109MXL | 221.488 | 109 | B212MXL | 430.784 | 212 | B365MXL | 741.68 | 365 | B762MXL | 1548.384 | 762 | |||
| B110MXL | 223.52 | 110 | B216MXL | 438.912 | 216 | B371MXL | 753.872 | 371 | B776MXL | 1576.832 | 776 | |||
| B112MXL | 227.584 | 112 | B220MXL | 447.04 | 220 | B372MXL | 755.904 | 372 | B805MXL | 1635.76 | 805 | |||
| B114MXL | 231.648 | 114 | B221MXL | 449.072 | 221 | B380MXL | 772.16 | 380 | B906MXL | 1840.992 | 906 | |||
| B115MXL | 233.68 | 115 | B222MXL | 451.104 | 222 | B388MXL | 788.416 | 388 | B930MXL | 1889.76 | 930 | |||
| B117MXL | 237.744 | 117 | B224MXL | 455.168 | 224 | B390MXL | 792.48 | 390 | B955MXL | 1940.56 | 955 | |||
| B118MXL | 239.776 | 118 | B225MXL | 457.2 | 225 | B397MXL | 806.704 | 397 | B1012MXL | 2056.384 | 1012 | |||
| B120MXL | 243.84 | 120 | B228MXL | 463.296 | 228 | B400MXL | 812.8 | 400 | B1060MXL | 2153.92 | 1060 | |||
| B122MXL | 247.904 | 122 | B229MXL | 465.328 | 229 | B402MXL | 816.864 | 402 | B1076MXL | 2186.432 | 1076 | |||
| B123MXL | 249.936 | 123 | B230MXL | 467.36 | 230 | B408MXL | 829.056 | 408 | B1078MXL | 2190.496 | 1078 | |||
| B125MXL | 254 | 125 | B232MXL | 471.424 | 232 | B412MXL | 837.184 | 412 | B1088MXL | 2210.816 | 1088 | |||
| B126MXL | 256.032 | 126 | B235MXL | 477.52 | 235 | B419MXL | 851.408 | 419 | B1137MXL | 2310.384 | 1137 | |||
| B127MXL | 258.064 | 127 | B236MXL | 479.552 | 236 | B420MXL | 853.44 | 420 | B1166MXL | 2369.312 | 1166 | |||
| B128MXL | 260.096 | 128 | B239MXL | 485.648 | 239 | B421MXL | 855.472 | 421 | B1250MXL | 2540 | 1250 | |||
| B129MXL | 262.128 | 129 | B240MXL | 487.68 | 240 | B424MXL | 861.568 | 424 | B1380MXL | 2804.16 | 1380 | |||
| B130MXL | 264.16 | 130 | B243MXL | 493.776 | 243 | B425MXL | 863.6 | 425 | B1392MXL | 2828.544 | 1392 | |||
| B131MXL | 266.192 | 131 | B245MXL | 497.84 | 245 | B427MXL | 867.664 | 427 | B1463MXL | 2972.816 | 1463 | |||
| B132MXL | 268.224 | 132 | B248MXL | 503.936 | 248 | B431MXL | 875.792 | 431 | B1516MXL | 3080.512 | 1516 | |||
| B134MXL | 272.288 | 134 | B249MXL | 505.968 | 249 | B434MXL | 881.888 | 434 | B1520MXL | 3088.64 | 1520 | |||
| B135MXL | 274.32 | 135 | B250MXL | 508 | 250 | B436MXL | 885.952 | 436 | B1778MXL | 3612.896 | 1778 | |||
| B136MXL | 276.352 | 136 | B251MXL | 510.032 | 251 | B440MXL | 894.08 | 440 | B1806MXL | 3669.792 | 1806 | |||
| B137MXL | 278.384 | 137 | B256MXL | 520.192 | 256 | B442MXL | 898.144 | 442 | B2044MXL | 4153.408 | 2044 | |||
| B138MXL | 280.416 | 138 | B262MXL | 532.384 | 262 | B447MXL | 908.304 | 447 | ||||||
| B139MXL | 282.448 | 139 | B265MXL | 538.48 | 265 | B448MXL | 910.336 | 448 | ||||||
| B140MXL | 284.48 | 140 | B267MXL | 542.544 | 267 | B453MXL | 920.496 | 453 | ||||||
| B142MXL | 288.544 | 142 | B271MXL | 550.672 | 271 | B458MXL | 930.656 | 458 | ||||||
| B144MXL | 292.608 | 144 | B273MXL | 554.736 | 273 | B463MXL | 940.816 | 463 | ||||||
| B145MXL | 294.64 | 145 | B275MXL | 558.8 | 275 | B466MXL | 946.912 | 466 | ||||||
| B148MXL | 300.736 | 148 | B280MXL | 568.96 | 280 | B472MXL | 959.104 | 472 | ||||||
| B150MXL | 304.8 | 150 | B285MXL | 579.12 | 285 | B475MXL | 965.2 | 475 | ||||||
| B151MXL | 306.832 | 151 | B288MXL | 585.216 | 288 | B482MXL | 979.424 | 482 | ||||||
| B154MXL | 312.928 | 154 | B290MXL | 589.28 | 290 | B487MXL | 989.584 | 487 | ||||||
| B155MXL | 314.96 | 155 | B295MXL | 599.44 | 295 | B488MXL | 991.616 | 488 | ||||||
| B156MXL | 316.992 | 156 | B298MXL | 605.536 | 298 | B490MXL | 995.68 | 490 | ||||||
| B158MXL | 321.056 | 158 | B300MXL | 609.6 | 300 | B497MXL | 1009.904 | 497 | ||||||
| B160MXL | 325.12 | 160 | B310MXL | 629.92 | 310 | B498MXL | 1011.936 | 498 | ||||||
| B162MXL | 329.184 | 162 | B312MXL | 633.984 | 312 | B500MXL | 1016 | 500 | ||||||
| B163MXL | 331.216 | 163 | B315MXL | 640.08 | 315 | B505MXL | 1026.16 | 505 | ||||||
| B165MXL | 335.28 | 165 | B318MXL | 646.176 | 318 | B522MXL | 1060.704 | 522 | ||||||
| B166MXL | 337.312 | 166 | B323MXL | 656.336 | 323 | B535MXL | 1087.12 | 535 | ||||||
| B167MXL | 339.344 | 167 | B324MXL | 658.368 | 324 | B537MXL | 1091.184 | 537 | ||||||
| B169MXL | 343.408 | 169 | B328MXL | 666.496 | 328 | B540MXL | 1097.28 | 540 | ||||||
| B170MXL | 345.44 | 170 | B330MXL | 670.56 | 330 | B543MXL | 1103.376 | 543 | ||||||
| B171MXL | 347.472 | 171 | B332MXL | 674.624 | 332 | B546MXL | 1109.472 | 546 | ||||||
| B175MXL | 355.6 | 175 | B334MXL | 678.688 | 334 | B548MXL | 1113.536 | 548 | ||||||
| B177MXL | 359.664 | 177 | B337MXL | 684.784 | 337 | B571MXL | 1160.272 | 571 | ||||||
| B180MXL | 365.76 | 180 | B339MXL | 688.848 | 339 | B591MXL | 1200.912 | 591 | ||||||
| B184MXL | 373.888 | 184 | B340MXL | 690.88 | 340 | B592MXL | 1202.944 | 592 | ||||||
| B186MXL | 377.952 | 186 | B342MXL | 694.944 | 342 | B599MXL | 1217.168 | 599 | ||||||
| B190MXL | 386.08 | 190 | B343MXL | 696.976 | 343 | B612MXL | 1243.584 | 612 | ||||||
| B192MXL | 390.144 | 192 | B347MXL | 705.104 | 347 | B648MXL | 1316.736 | 648 | ||||||
| B194MXL | 394.208 | 194 | B350MXL | 711.2 | 350 | B694MXL | 1410.208 | 694 |
